AK-FIX

Non-absorbable SOFTFIX-PK® interference screw incorporates PEEK-VESTAKEEP® polymer from Evonik® which exhibits an ideal combination of strength, stiffness and toughness that surpasses absorbable materials. It provides the interference screw fixation, while eliminating the need of trans osseous tunnels in tendon repairs and ligament reconstruction. It can be used for Distal Biceps Repair. Dimensions: Dia. 4.0mm x Len. 10.0mm & 15.0mm and Dia. 5.0mm x Len. 15.0mm & 20.0mm

The FIBERKNOT® soft ligament anchor is composed of ultra-high molecular weight polyethylene (UHMWPE) suture and is available in diameter of 1.8mm (double loaded). FIBERKNOT® requires a smaller pilot hole compared to traditional anchors, minimizing bone removal and decreasing the overall anchor footprint, while still providing superior strength. Anchor Dimensions: 1.8mm x 15.0mm Type: Tap-in/Bang-on suture anchor Suture / Tape Colour: White-Blue, White-Black

The MINI-VIM® Ligament anchors are titanium anchors available in 2.8mm, 3.5mm diameter and come preloaded with USP #2 suture and needle. The implant can be manually inserted using the handled version. A drill is available for use in hard bone if desired. Anchor Dimensions: 2.8mm x 11.5mm, 3.5mm x 11.5mm Type: Screw in suture anchor Suture Colour: White

The MINI-VIM PK® Ligament anchor, Knotless are available in diameter of 2.8mm & 3.5mm. It is a non-absorbable PEEK suture anchor with a material eyelet which provides superior abrasion resistance due to PEEK’s low coefficient friction. The knotless technology of MINI-VIM PK® Ligament anchor provides a step-saving alternative to conventional “knotted” suture anchors and eliminates “knot stacks” associated with soft tissue irritation. Anchor Dimensions: 2.8mm x 12.0mm, 3.5mm x 12.0mm Type: Tap-in/Bang-on suture anchor Suture Colour: White-Green (Holding Suture)
